Air Jet Mill Production Machines

Precision at scale, productivity to the max

Micronise with greatest precision, achieve best yield with operator safety!

Micron Miller production Air Jet Mills are a competitive advantage for fine powder processing requirements. These machines are designed to deliver precision, yield, safety, and productivity at scale.
Built to handle large batch sizes and easy changeovers, our Air Jet Mills also ensure shorter changeover time, which means better productivity in the same duration
These robust machines meet global safety standards and inspire confidence and peace of mind for operators.

Key Features Of Micron Miller

Commercial Scale Models

Scale up production, get better yield with superior accuracy

Precise Particle Size Control

Adjust settings to achieve exact micron levels even for larger powder batches.

Scale with efficiency

Built for GMP environments. these machines are safe and Scalable from lab to production levels.

Material Versatility

Works with hard, soft, and heat-sensitive materials without compromising quality.

Bag-filters for contamination control

Well designed bag filters works as containment and product-recovery device. Minimises product loss. Contamination risk is controlled.

Rapid Assembly OR Disassembly

Reduces downtime, lower labour cost and operator fatigue, minimizes contamination risk.

Precise Monitoring

Full-batch reporting, PAT and on-line particle size analyzers available.

Sterile Manufacturing

For superior purity via UV Light or any other suitable method. Supports GMP workflows.

CFD-driven design

Optimized nozzle and chamber geometry for efficient milling and particle size precision at scale.

Liner Options

Choose liners based on abrasiveness — ceramic or titanium nitride where needed.

Flexible Process Control & Configuration

You get better control over Particle Size Distribution by adjusting 3 parameters-- milling pressure, feed pressure, and feed rate.
You can choose a feeding system. Vibratory feeding as well as VFD Controlled Screw Type – Volumetric feeding is available.
For bag filters, you have a choice between pneumatic shaking or reverse pulse. HEPA too, available on request.

Micron Miller commercial air jet mill machines helps you achieve productivity with precision and safety

Wide Processing Range

Micron Miller air jet mills cover the full spectrum of particle-size and throughput needs: from ultra-fine powders in gram-scale to high-throughput production lines which handles hundreds of kilograms per hour.

High-Speed Precision

Our machines ensure precision particle-size control even at high throughput and higher speeds.

Minimal Material Loss

Our high yield with minimal wastage capability saves a lot for your organisation.

Low Energy Consumption

Our low energy consumption design saves you even more.

Robust & Reliable Design

Robust design evokes a sense of safety and confidence in operators. Low downtime ensures higher productivity for commercial scale powder processing.

We are here to assist your R&D initiatives!

Enquire Now

Specifications

Jet Mill Size	Energy Requirement (SCFM)	Compressor HP Approximate	Capacity (KG/HR)	Capacity (LBS/HR)
Jet Mill Size	Energy Requirement (SCFM)	Compressor HP Approximate	Capacity (KG/HR)	Capacity (LBS/HR)
2	20	5	0.2 – 0.9	1/2 – 2
4	55	13	0.9 – 18	2 – 40
8	130	31	4 – 45	10 – 100
12	260	62	13 – 113	30 – 250
15	350	83	22 – 136	50 – 300
20	550	130	45 – 453	100 – 1000
24	1000	236	113 – 635	250 – 1400
30	1500	354	272 – 1360	600 – 3000
36	2250	531	453 – 2721	1000 – 6000
42	3300	779	907 – 4550	2000 – 10000

Micro Miller Air Jet Mills:

Applications Across Industries

Pharmaceuticals

Micronize drugs to improve absorption and bioavailability. Test grinding parameters to get consistent particle size without degrading active ingredients.
Helps Scientists to micronise and test for their stability, coating, dissolution etc.

Chemicals & Pigments

Develop fine pigments with uniform particle size to enhance color strength and stability. R&D experts can experiment with air pressure and feed rates to optimize particle size distribution. This helps in brighter, more stable colors and better dispersion in paints or plastics.

Food Industry

Develop fine powders (e.g., spices, sugar, milk powder) for improved texture and solubility. Scientists can adjust milling conditions to retain flavor and nutritional value. Achieve enhanced taste, quicker mixing, and innovative food textures.

Cosmetics

Create smooth powders for makeup that feel light and apply evenly. To achieve this scientists can fine-tune milling to achieve the right particle size for skin feel. It results in smooth texture, uniform appearance, and skin absorption.

Materials & Ceramics

Our R&D Air Jet Mills are suitable to prepare ultra-fine powders for advanced ceramics and composites. R&D Engineers can control particle size to improve sintering and mechanical properties. It enables you to develop stronger, more durable materials with precise characteristics.

Micro Miller Air Jet Mills:

Applications Across Industries

Pharmaceuticals

Chemicals & Pigments

Food Industry

Cosmetics

Materials & Ceramics

Production Air Jet Mill

What is the primary use of Micron Miller Production scale Air Jet Mill?

How does Air Jet Mill achieve precise particle size control?

What features are there in Micron Miller Air Jet Mills to ensure easy cleaning and maintenance?

What feeding system options are available?

What bag filter options available for contamination control?

What liner options are available for abrasive materials?

Can Micron Miller Air Jets handle high throughput requirements?

How does the Air Jet Mill ensure operator safety?
